SAM450
Unparalleled Strength + Capabilities
Perfect for A-list performances and large crowds, the SAM450 is large yet nimble - boasting a rigging capacity of 66,000 lbs and cutting edge bolted trusses yet also movable rigging bears and multiple covered wing configurations.
Technical SpecsSpecifications
.01
Length + Depth
44' x 38'4"
.02
Height from Ground
5'3"–6'6"
.03
Integrated Roof Height from Deck (Inclined roof)
27'–24'8"
.04
Flown Sound Capacity
3,000 lbs per side
Many different sound hang points. Lowest maximum is 2,000 lbs can technically go all the way to 10,000 lbs. 3,000 lbs capacity is in most common stage configurations.
.05
Roof Lifting Capacity
4,000 lbs
.06
Overhead Clearance Once Built
35'8"–40'10"
.07
Roof Load Bearing Capacity
66,000 lbs
.08
Min. Base Stage Set-Up Time
4 hrs
including time for landing and leveling
.09
Min. Number of Stage Technicians
4
.10
Mode of Transportation
1 tractor trailer
.11
Required Overhead Clearance for Travel
13'5"
.12
Gust Wind Resistance
77 mph w/ windwalls; 115 mph w/out windwalls
.13
Wind Wall Coverage
Full-Width Back Wall in Vinyl and Full-Depth Side Walls in Vinyl
full covered side wing
(3.21MB)
