SL100
Compact + Capable
The ST100 is a versatile mid-size mobile stage designed for quick setups and adaptable configurations. With a strong deck footprint and generous trim height, it’s perfect for community events, concerts, and street festivals. Built-in rigging points and optional side truss add flexibility for lighting, audio, and banners—making the SL100 a smart choice for mid-scale productions that still want to make a big impression.
Technical SpecsSpecifications
.01
Length + Depth
24' x 20'
Expandable with optional deck wings and rear extensions
.02
Height from Ground
3'6"–4'6"
.03
Integrated Roof Height from Deck (Inclined roof)
14'7"–13'9"
.04
Flown Sound Capacity
800 lbs per side; 2,500 lbs Capability*
2,500 lbs capability with line array and screen rigging per side for models 2018 and newer
.05
Roof Lifting Capacity
3,800 lbs
.06
Overhead Clearance Once Built
19'–25'
.07
Roof Load Bearing Capacity
6,500 lbs
.08
Min. Base Stage Set-Up Time
1 hr
including time for landing and leveling
.09
Min. Number of Stage Technicians
2
.10
Mode of Transportation
1 pick-up truck
.11
Required Overhead Clearance for Travel
11'2"
.12
Gust Wind Resistance
77mph w/ windwalls; 102 mph w/out windwalls
.13
Wind Wall Coverage
Full-Width Back Wall in Vinyl and Full-Depth Side Walls in Vinyl
