SL50
Versatile + Compact
The SL50 is the most compact stage in our inventory. Meant to fit into tight spots and set up quickly, this stage is a turnkey solution for a wide variety of events.
Technical SpecsSpecifications
.01
Length + Depth
20' x 16'
.02
Height from Ground
3'–3'6"
.03
Integrated Roof Height from Deck (Inclined roof)
11'–9'5"
.04
Flown Sound Capacity
375 lbs per side
.05
Roof Lifting Capacity
200 lbs
.06
Overhead Clearance Once Built
15'–17'
.07
Roof Load Bearing Capacity
2,500 lbs
.08
Min. Base Stage Set-Up Time
1 hr
including time for landing and leveling
.09
Min. Number of Stage Technicians
2
.10
Mode of Transportation
1 pick-up truck
.11
Required Overhead Clearance for Travel
9'11"
.12
Gust Wind Resistance
77 mph w/ windwalls; 102 mph w/out windwalls
.13
Wind Wall Coverage
Full-Width Back Wall in Mesh or Vinyl and 1/3-Depth Side Wall in Vinyl
Download Full Specs PDF
(1.27MB)
